Special Made Gantry Frame Welding Machine for Lab Use

Quantity:

In this section we will introduce a gantry frame welding machine designed and produced for a famous overseas welding company of branch in China, which would be used in their welding laboratory for validating SAW (Submerged Arc welding) technique. So, it is a special made welding equipment for special use.



  1. Request from Customer:

    1)       This special made gantry welding machine should be capable of making independent running of welding head and its carriage;

    2)       Welding mode is SAW (Submerged Arc welding);

    3)       The entire set of special made welding machine should have good stability, high rigidity, flexible and convenient operation;

    4)       The equipment can work steadily and reliably within the range of 150A~ 1300A within fluctuation tolerance of ±5%;

    5)       This special made welding machinery should be equipped with workpiece worktable. The worktable is designed and made based on workpiece type.



   2. Main Units:

    1)     The complete set of special purpose welding machinery is composed of mechanical machine body of gantry frame; SAW power supply, welding console, and wire feeder;

    2)     SAW Power Supply:

    a)  Main Parameters:

Rated Welding   Current

1000 A

Rated Duty   Cycle

100%

Input   Electricity Specification

3P 380V ±10%,50Hz±1Hz

Output Current

150 ~ 1300 A

No Load   Voltage

Up to 75V

    b)  Main Function and Features:

     i.           It is a kind of multi-function welding power supply. It can be used in both submerges arc welding, and open arc welding;

    ii.           It can be used in various welding equipment, including general purpose and special welding machinery;

   iii.           Constant voltage and constant current;

   iv.           Average working life is 15 years in the working mode of 3 shifts;

    v.           Remote control available, and welding parameter adjustment with console;

   3)    Welding Console:

   a)       Precise management of welding technology, arc striking characteristic, welding start and stop, welding seam dimension and appearance, reducing welding cost for both “ordinary” and specialized welding machinery;

   b)      Productivity is raised thanks to its high deposition rate, high welding speed and eliminating bottleneck;

   c)       Welding program, wire feeding speed, wire size, welding parameters, and welding mode can be modulated very easily within extensive range. This is especially beneficial for specialized welding equipment;

   4)     Wire feeder:

    a)       Wire feeding range is 0.4~ 7.4m/min., wire diameter range is ф2.4-ф5.6mm;

    b)      Wire feeding box reduction ratio is 142:1, and optional 95:1 is available for special welding equipment;

    c)       Wire feeding is powered with D.C. motor, managing wire feeding speed precisely;

    d)      Best pressure fitting by means of adjustable spring for clamping welding wire, avoiding wire deformation;

    e)        Wire feeding head can be revolved in full position, equipped with wire straightener, meeting high demand of all kinds of welding application, including SAW in this special made gantry welding machine;

    5)     Gantry Frame:

It is the body and trunk of this special made welding machine. It can be summarized in the form of below parameters:

No.

Parameter

Specification

Note

1

Gantry Beam Length

4000mm


2

Valid Stroke of Welding Carriage

3400mm


3

Welding Velocity

100~1000mm/min


4

Welding   Velocity Adjustment

Stepless control with inverter


5

Vertical and Horizontal Adjusting Stroke of Welding Head

200mm

Manual

6

Welding Carriage Travel Transmission

Gear and Rack Couple


7

Welding Carriage Travel Guideway

Precise Ball Bearing Linear Guideway


8

Welding Torch   Tilting Range

-30°~30°


9

Gantry Height

Based on 700mm Height Work table


10

Distance between Welding Torch and front   side of Gantry Beam

400 ~ 500mm
