The Category of CNC Strip Plate Cutting machine and How to Select

1.       Topics of this Article on CNC Strip Plate Cutting machine:

In this article, as professional manufacturer on CNC Strip Plate Cutting machine, we will discuss on the equipment as below:

1)       The Usage and Wide Application of CNC Strip Plate Cutting machine;

2)       Classification on CNC Plate Cutting machine and Brief on Application Field;

3)       Brief Introduction on CNC Flame Plate Cutting machine;

4)       Brief Introduction on CNC Plasma Plate Cutting machine;

5)       Brief Introduction on CNC Flame Plasma Plate Cutting machine, Strip Plate Cutting machine, and Triple Plate Cutting machine.


2.       The Usage and Wide Application of CNC Strip Plate Cutting machine:

1)       CNC Strip Plate Cutting machine is the basic and indispensable equipment in modern production industry, across all fields, facilities and plant where involve using of metal plates as raw material for manufacturing process;

2)       With these CNC Strip Plate Cutting machine, metal plates of various materials: Carbon steel, stainless steel, Al, Brass… can be cut into designed shape and size in batch, with consistent high precision in high productivity. This is the precondition on all the process technology of diversified finished products.


3.       Classification on CNC Plate Cutting machine and Brief on Application Field:

Depending on thermal cutting technology applied, the CNC Plate Cutting machine can be divided into three broad categories of CNC Flame Plate Cutting machine, CNC Plasma Plate Cutting machine and Laser CNC Plate Cutting Machine;

1)       Specialty of CNC Flame Plate Cutting machine:

CNC Flame Plate Cutting machine

a)       CNC Flame Plate Cutting machine is the earliest product of CNC Strip Plate Cutting machine, and the most cost effective equipment among the three major types of CNC Plate Cutting machine;

b)      CNC Flame Plate Cutting machine is most applicable for cutting carbon steel, especially thick plate. For standard specification of CNC Flame Plate Cutting machine, the cutting thickness can be up to 100mm; The special made CNC Flame Plate Cutting machine can cut the maximum thickness of 200mm;

2)       Specialty of CNC Plasma Plate Cutting machine:

CNC Flame Plate Cutting machine

a)       CNC Plasma Plate Cutting machine is the intermediate product in product family of CNC Strip Plate Cutting machine, in terms of history, cost, and fineness of cutting kerf;

b)      CNC Plasma Plate Cutting machine has the same equipment frame as CNC Flame Plate Cutting machine. The difference is, CNC Plasma Plate Cutting machine adopts plasma power supply as its cutting energy source, which determines cutting capacity of the machine based on its model, and hence output cutting current and voltage;

3)       Specialty of Laser CNC Plate Cutting machine:

Laser CNC Plate Cutting machine is the latest developed type of CNC Plate Cutting machine. It has the highest cutting speed, the finest cutting kerf, and the highest machine quotation.


4.       Brief Introduction on CNC Flame Plate Cutting machine:

1)       Working Principle of CNC Flame Plate Cutting machine:

CNC Flame Plate Cutting machine

a)       CNC Flame Plate Cutting machine is the earliest developed type of CNC Plate Cutting machine. Utilizing the combustion of iron in Oxygen, the metal plate is cut in expected shape;

CNC Flame Plate Cutting machine

b)      The most applicable material for such way of thermal cutting is carbon steel, which is the most widely selected raw material in manufacturing industry. This is also the reason why CNC Flame Plate Cutting machine got such extensive application of the longest history;

2)       The Advantage of CNC Flame Plate Cutting machine:

a)       CNC Flame Plate Cutting machine has strong capability on cutting big thickness, especially for cutting metal plates thicker than 45mm, CNC Flame Plate Cutting machine has incomparable superiority: Currently CNC Flame Plate Cutting machine is only equipment capable of cutting thickness above 50mm;

b)      The lowest cost in terms of equipment purchase and running cost: Compared with CNC Plasma Plate Cutting machine and Laser CNC Plate Cutting Machine, CNC Flame Plate Cutting machine has the bottom equipment quotation and variable cost in its daily operation. This is also the other reason why CNC Flame Plate Cutting machine is so widely welcomed over the past several decades;

3)       The Disadvantage of CNC Flame Plate Cutting machine:

No any equipment is flawless. This is also true with CNC Flame Plate Cutting machine:

a)       Compared with CNC Plasma Plate Cutting machine and Laser CNC Plate Cutting Machine, cutting kerf delivered from CNC Flame Plate Cutting machine is rough, which sometimes need to be trimmed when special requirement on fineness of cutting kerf is demanded;

b)      Compared with CNC Plasma Plate Cutting machine, cutting speed of CNC Flame Plate Cutting machine is slower: ≦1000mm/ min.


5.       Brief Introduction on CNC Plasma Plate Cutting machine:

1)       Working Principle of CNC Plasma Plate Cutting machine:

CNC Plasma Plate Cutting machine

a)       By means of plasma arc generated under high electric field and high temperature, the metal plate is locally fused and cut: This is working way of CNC Plasma Plate Cutting machine;

b)      CNC Plasma Plate Cutting machine shares the same structure and size of mechanical frame as CNC Flame Plate Cutting machine. It uses plug in different models of plasma power supply, based on required cutting capacity of the CNC Plasma Plate Cutting machine demanded from customer;

CNC Plasma Plate Cutting machine

c)       Wider scope of materials is available for being cutting in CNC Plasma Plate Cutting machine than CNC Flame Plate Cutting machine: Stainless Steel, Al, Zinc, Brass, etc. The Max. thickness applicable for being cutting in CNC Plasma Plate Cutting machine is 45mm;

2)       The Advantage of CNC Plasma Plate Cutting machine:

a)       Compared with CNC Flame Plate Cutting machine, the cutting kerf from CNC Plasma Plate Cutting machine is finer with much less heat deformation;

b)      Productivity of CNC Plasma Plate Cutting machine is higher: Cutting speed can be up to 6000mm/min.;

3)       The Disadvantage of CNC Plasma Plate Cutting machine:

a)       Daily running of CNC Plasma Plate Cutting machine is relative complicated and in high cost: It involves selection on proper model of series of consumables: From electrode, to nozzle, to cutting sleeve… This entails fairly budget on variable cost of CNC Plasma Plate Cutting machine;

b)      Cutting process of CNC Plasma Plate Cutting machine usually generates fairly amount of fume, arc light and noise, which may do harm on operator health. For this reason, Operator should put on proper PPE when operating the CNC Plasma Plate Cutting machine.


6.       Brief Introduction on CNC Flame Plasma Plate Cutting machine, Strip Plate Cutting machine, and Triple Plate Cutting machine:

Besides the above introduced CNC Flame Plate Cutting machine and CNC Plasma Plate Cutting machine, there are some types of branch product of CNC Strip Plate Cutting machine:

1)       CNC Flame Plasma Plate Cutting machine:

CNC Flame Plasma Plate Cutting machine

This is combination of CNC Flame Plate Cutting machine and CNC Plasma Plate Cutting machine into one equipment, so that customer can utilize applicable advantages of both types of equipment;

2)       Strip Plate Cutting machine:

Strip Plate Cutting machine

a)       Strip Plate Cutting machine is branch product of CNC Flame Plate Cutting machine. Using the same type of flame cutting, Strip Plate Cutting machine cuts carbon steel plate into strip plate;

b)      One of the major applications of Strip Plate Cutting machine is H Beam Production Line;

3)       Triple Plate Cutting machine:

Triple Plate Cutting machine


Triple Plate Cutting machine is used for cutting beveling on edge of carbon steel. It has similar purpose as Edge Milling Machine, but in different working style, and delivers different fineness of cutting kerf.


7.       Summary on CNC Strip Plate Cutting machine:

As professional manufacturer on various types and models of CNC Plate Cutting machine with over 20s years of rich experience, Wuxi JACK has capability on delivering various CNC Strip Plate Cutting machine of top grade for customers across industry. If you are interested, please pay a visit to product family of CNC Strip Plate Cutting machine.
